From the deepest bass to the sharpest and sweetest highs, the Wega100 DIY amplifier drives any speaker system and is our most cleverly crafted amplifier ever.
Designed and built with a great passion for hi-fi audio reproduction, the Wega100 utilizes the finest electronics available on the market to control and drive your speakers better than you ever imagined possible. The amplifier uses the renowned STK module for the output stage, known for its exceptional sound quality and low distortion. With excellent linearity in response, 100 watts per channel is powerful enough to drive any big speaker system. Equipped with tone controls for bass and treble, the Wega100 allows you to fine-tune your sound like a master chef fine-tunes their ingredients. It even has the capability to produce surround sound with just a pair of speakers, giving you an immersive and spatial listening experience. Developed as a very practical solution, it integrates various features such as FM, USB input, and Bluetooth connectivity. The spectrum analyzer provides a visual representation of the sound, making it easier to understand and offering a sleek, advanced look that appeals to users who appreciate high-tech features.
Design and Craftsmanship
The Wega100 is built using the best electronic components available on the market. The STK module used in the output stage is celebrated for its high sound quality, low distortion, and excellent linearity. To ensure optimal performance, the amplifier includes a large heatsink for superior heat dissipation, so you never have to worry about overheating problems.
The cleverly designed boosting curve for the bass and treble controls delivers unparalleled results. Utilizing the LM1036 tone controller, known for its high quality, low distortion, and high gain of controls, the Wega100 allows precise adjustments to the audio output. Additionally, it features modern and advanced sound-enhancing capabilities with the AViSS 3D surround algorithm for virtual surround sound.
The Wega100 is a practical solution with Bluetooth and USB connectivity and FM radio integration. It also includes built-in speaker protection against short circuits, ensuring the longevity and safety of your audio equipment.
Performance
The Wega100 is a perfect choice for home hi-fi audio, and any audiophile will appreciate its performance. It can produce 100W + 100W per channel with an impedance of 8 ohms. The excellent tone controls provide a gain of +/- 15dB at 40Hz, with an excellent boosting curve at the lower end to produce deep and rich bass that everyone loves to hear. The treble controls offer a gain of +/- 15dB at 16kHz, allowing you to adjust crisp, sharp, and clear treble. Loudness compensation helps to respond to the non-linearity of human hearing for high and low-end frequencies. The surround sound option guarantees an immersive listening experience, delivering high-quality virtual surround sound with just a pair of speakers.
Specifications
- Power output: 100W + 100W (8 ohms)
- Load resistance: 8 ohms
- Total harmonic distortion: 0.3% (Po 1.0 W, 1 kHz)
- Frequency response: 20 to 50 kHz (+/- 3 dB)
- Tone control (bass): +/- 15 dB at 40 Hz
- Tone control (treble): +/- 15 dB at 16 kHz
- Sound effects: AViSS 3D surround / Loudness Compensation
- Balance control range: -20 dB
- Volume control range: 75 dB
- Operating voltage: 220 ACV
Development
Rasan Samarasinghe, Colombo, Sri Lanka. • LinkedIn
